RS-R SPORTS *i COILOVER: TOYOTA SUPRA A90 2020

Part Number: XBIT215M Compatibility: 2020+ Toyota Supra Chassis code: DB42/DB22

Preset Approximate Height

Front: -30mm to -35mm (-1.2in to -1.4in) Rear: -40mm to -45mm (-1.6in to -1.8in)

Maximum Adjustment Range

Front: -5mm to -80mm (-0.2in to -3.2in) Rear: -15mm to -70mm (-0.6in to -2.8in)

Recommended Adjustment Range

Front: -10mm to -55mm (-0.4in to -2.2in) Rear: -15mm to -70mm (-0.6in to -2.8in)

Spring Rate

Front: 8.00kg/mm Rear: 14.0kg/mm

Additional Information

Damper Warning Canceler is not included. If the canceler is not installed, an error message is displayed and the traction control off system will not function Dampers are 36 way adjustable in the front and the rear Warranty: 1 Year / 12,000 miles from the day of purchase
